7511 - Bracket Type: 6026-01
Aluminum Mounting Bracket
Horizontally Adjustable
Minimum post size 2½" x 2 ½" (64x64mm) required.
For Aluminum Post:
Predrill using 1/4" (6mm) drill bit and use #18 countersunk through bolts or fasteners.
For Steel or Stainless Post:
Brackets can be fastened by drilling and tapping or with through bolts.

7512 - Bracket Type: 6026-02
Aluminum Mounting Bracket
Horizontally Adjustable
Minimum post size 2½" x 2 ½" (64x64mm) required.
For Aluminum Post:
Predrill using 3/16" (5mm) drill bit and use #14 countersunk through bolts or fasteners.
For Steel or Stainless Post:
Brackets can be fastened by drilling and tapping or with through bolts.

7513 - Bracket Type: 6026-03
Aluminum Mounting Bracket
Horizontally Adjustable
Minimum post size 4"x4" (100x100mm) required.
For Aluminum Post:
Predrill using 3/16 (5mm) drill bit and use #14 countersunk through bolts or fasteners.
For Steel or Stainless Post:
Brackets can be fastened by drilling and tapping or with through bolts.

7514 - Bracket Type: 6026-04
Aluminum + Clamp Mounting Bracket.
Added fixing clamp prevents slippage.
Minimum post size 2½" x 2 ½" (64x64mm) required.
For Aluminum Post:
Predrill using 3/16" (5mm) drill bit and use #14 countersunk through bolts or fasteners.
For Steel or Stainless Post:
Brackets can be fastened by drilling and tapping or with through bolts.

7515 - Bracket Type: 6026-05
Aluminum Mounting Bracket
Minimum post size 2"x2" (50x50mm) required.
For Aluminum Post:
Predrill using 1/4" (6mm) drill bit and use #14 countersunk through bolts or fasteners.
For Steel or Stainless Post:
Brackets can be fastened by drilling and tapping or with through bolts.
