Galvanized Bolt Type Anchor Shackles
- Bolt Type Anchor Shackles
- Installation Info
|
| Galvanized Bolt Type Anchor Shackles |
GALV. |
Nominal
Size
(in) |
Part No. |
WLL*
(lbs) |
"D"
STOCK
SIZE |
"G"
OPENING |
"E"
EYE
WIDTH |
"J"
EYE
DEPTH |
"L"
LENGTH |
"W"
WIDTH |
"H"
HEIGHT |
"S"
PIN
DIA. |
Tolerance
+/- |
| "J" |
"G" |
| 1/4" |
RSBA08G |
1,000 |
.25" |
.47" |
.78" |
1.13" |
1.28" |
.61" |
1.84" |
.31" |
.06" |
.06" |
| 5/16" |
RSBA10G |
1,500 |
.31" |
.53" |
.84" |
1.22" |
1.47" |
.75" |
2.09" |
.38" |
.06" |
.06" |
| 3/8" |
RSBA12G |
2,000 |
.38" |
.66" |
1.03" |
1.44" |
1.78" |
.91" |
2.49" |
.44" |
.13" |
.06" |
| 7/16" |
RSBA14G |
3,000 |
.44" |
.75" |
1.16" |
1.69" |
2.03" |
1.06" |
2.91" |
.50" |
.13" |
.06" |
| 1/2" |
RSBA16G |
4,000 |
.50" |
.81" |
1.31" |
1.88" |
2.31" |
1.19" |
3.28" |
.63" |
.13" |
.06" |
| 5/8" |
RSBA20G |
6,250 |
.63" |
1.06" |
1.69" |
2.38" |
2.94" |
1.50" |
4.19" |
.75" |
.13" |
.06" |
| 3/4" |
RSBA24G |
8,250 |
.75" |
1.25" |
2.00" |
2.81" |
3.50" |
1.81" |
4.97" |
.88" |
.25" |
.06" |
| 7/8" |
RSBA28G |
13,000 |
.88" |
1.44" |
2.28" |
3.31" |
4.03" |
2.09" |
5.83" |
1.00" |
.25" |
.06" |
| 1" |
RSBA32G |
17,000 |
1.00" |
1.69" |
2.69" |
3.75" |
4.69" |
2.38" |
6.56" |
1.13" |
.25" |
.06" |
| 1-1/8" |
RSBA36G |
19,000 |
1.13" |
1.81" |
2.91" |
4.25" |
5.16" |
2.29" |
7.47" |
1.25" |
.25" |
.06" |
| 1-1/4" |
RSBA40G |
24,000 |
1.25" |
2.03" |
3.25" |
4.69" |
5.75" |
3.00" |
8.25" |
1.38" |
.25" |
.06" |
| 1-3/8" |
RSBA44G |
27,000 |
1.38" |
2.25" |
3.63" |
5.25" |
6.38" |
3.31" |
9.16" |
1.50" |
.25" |
.13" |
| 1-1/2" |
RSBA48G |
34,000 |
1.50" |
2.38" |
3.88" |
5.75" |
6.88" |
3.63" |
10.00" |
1.63" |
.25" |
.13" |
| 1-3/4" |
RSBA56G |
50,000 |
1.75" |
2.88" |
5.00" |
7.00" |
8.86" |
4.19" |
12.34" |
2.00" |
.25" |
.13" |
| Please click on part number to order. |
| * NOTE: Maximum Proof Load is 2.0 times the Working Load Limit. Minimum Ultimate Strength is 6 times the Working Load Limit. |
|
|
|
